H3C's SD-WAN solution for branch networks, with zero-touch rollout, automatic VPN and QoS, application-aware path selection and WAN optimisation.
Island-wide delivery to all 25 districts
| Specification category | Item / Remarks |
|---|---|
| Networking scenario | Hub-spoke network / Supports the hub-spoke network model. |
| Full-mesh | Supports the full-mesh network model. |
| Partial-mesh | Supports flexibly customizing partial-mesh based on the hub-spoke or full-mesh network model. |
| Multi-instance network | Allows a single controller to manage multiple independent enterprise branch networks. |
| Multi-hub network | Supports multi-HQ/DC networks. |
| Multi-layer netwok | Supports HUB-Aggregation-Branch or more layers network, and support cross layer forwarding. |
| POP network | Allows ISPs to provide tenants with cross-domain high-speed interconnect services based on POPs, and supports traffic engineering and service assurance between POPs. |
| System management | System management channel / The management channel between the device and the controller supports both IPv4 and IPv6. |
| Device access authentication | Supports hardware SN and software token methods. |
| User login authentication | Supports two-factor/multi-factor authentication methods, Radius, LDAP, TACACS authentication, and third-party server authentication. |
| Manage users | View, add, modify, delete, and disable management users, including binding administrators to organizations. |
| Permission Management | Supports RBAC. |
| Tenants | Supports hierarchal multitenancy, and supports MSP tenants. |
| Theme Management | Supports dark and light themes, and supports switching between them. |
| Icons customizing | Support system logo, icon, title, copyright information, login page background image and other information changes. |
| Installation and deployment | System component deployment / Support localized deployment, public cloud deployment such as Azure and AWS, and enterprise private cloud deployment,. Support physical server and virtual machine deployment. Support disaster recovery mode, support manual switching and automatic switching. |
| Business component deployment | Support integrated deployment of RR and HUB CPE, support STUN server, POP gateway. |
| Multi time zone | Dashboard presents corresponding time information based on the user's time zone. |
| Component deployment | Supports smooth scaling-out from standalone mode to cluster mode. |
| Underlay deployment | Support Internet, Layer 2 dedicated line, Layer 3 dedicated line, VPDN dedicated line. Support configuration templates. |
| Configuration Wizard | Support network planning, batch onboarding, single site onboarding, and overlay network planning. |
| ZTP deployment | Supports four ZTP modes, including USB, email, DHCP, and public cloud; Support encrypted onboarding content and secure onboarding. |
| Network deployment | Support device management of basic information such as device name, management IP, serial number, software version, etc; Support site management; Support WAN and LAN network deployment; Support router protocols, router policies, and overlay business deployment. |
| IPv6 | Supports IPv4/IPv6 dual stack design for both the underlay and overlay. |
| Service management | VPN isolation / Supports service traffic isolation through VRF deployment |
| Application assurance QoS | Supports application assurance, application rate limiting, and interface rate limiting |
| ACL Template | Support IPv4/IPv6 ACL templates |
| Part numbers | LIS-IMO-SE-WAN, LIS-IMO-SE-WAN-BR-1, LIS-IMO-SE-WAN-DR, LIS-IMO-SE-WAN-BR-MBM-1, LIS-IMO-SE-WAN-VA-1, LIS-IMO-SA-WAN, LIS-IMO-SA-WAN-BR-1 |
