H3C WA6628E-T Wi-Fi 6 Rail Transit Access Point
An all-metal Wi-Fi 6 AP for trains and vehicles, with M12 connectors and resistance to strong electromagnetic interference.
Price on Request
Software-defined storage that pools server disks into one scale-out system providing block, file, object and big-data storage.
Island-wide delivery to all 25 districts
| Cluster size | Max. 4096 nodes |
|---|---|
| System structure | Fully symmetrical distributed architecture |
| Hard disk type | NVMe SSD, NL- SAS, SATA SSD, SATA HDD, SAS HDD |
| Front-end network | 1Gb/10Gbps/25Gbps Ethernet, InfiniBand network |
| Back-end network | 10Gbps/25Gbps Ethernet, InfiniBand network |
| Storage type | Block, File, Object, Big data |
| Storage protocol | iSCSI，RBD，NFS, CIFS，FTP，HTTP/HTTPS，S3，Swift，CSI，HDFS |
| Data redundancy | Replication (copies) level 2 to 6 / N+1 to N+4 erasure code |
| Data reconstruction | ＜20 minutes per TB |
| High availability | Node, port, network, management high availability |
| Software function | Link aggregation, Data balancing, Intelligent load balancing, Metadata separation deployment, Performance QoS, Data reconstruction QoS, Fault domain, Protection domain, Snapshot, SSD cache acceleration, Tiered storage, Consistency check, Safety permission, Disk Roaming, Disk sub-health detection, Software sub-health detection, Network sub-health management, Node sub-health management, etc. |
| Block value-added features | Thin provisioning, Thick provisioning, Volume copy, Cloning, Asynchronous remote replication, Multi-path, Hyper-converged deployment, etc. |
| File value-added features | WORM, Authority management, Quota management, Recycle bin, etc. |
| Object value-added features | Multi-tenant, WORM, Asynchronous remote replication, Compression, Encryption, Version management, Append Object, Quota, Life cycle management, ACL permission control, Policy strategy, Static website hosting, Cross-domain access, Custom metadata, etc. |
| Performance | 3-node cluster, single node 192GB memory, 10 SSD SATA, cluster IOPS up to 5W+ |
| Compatibility | Compatible with POSIX standard interface, Windows, Linux, UNIX, Mac OS, VMware ESXi and other operating systems, KVM, vSphere, Xen, Hyper-V and other virtualization platforms, compatible with Oracle, SQL Server, MySQL and other databases, compatible with OpenStack and H3C CloudOS platform (Swift, Cinder, Manila interface) |
| Cluster management | Support Log management, user management, decentralization and domain division, network management, alarm and fault management, capacity and performance management, support online expansion and contraction of nodes. Support SNMP protocol and third-party network management platform |
| Management method | Graphical interface, Web browser or CLI management |
An all-metal Wi-Fi 6 AP for trains and vehicles, with M12 connectors and resistance to strong electromagnetic interference.
A 12-stream Wi-Fi 6 flagship with an 8x8 5 GHz radio and 10G uplink for stadiums, auditoriums and lecture halls.
A Wi-Fi 6 AP with a 4x4 5 GHz radio and 5G multigigabit uplink for demanding indoor deployments.
An outdoor Wi-Fi 6 AP with two 2x2 radios, switchable to dual 5 GHz, plus PoE-out for cameras or sensors.
