H3C Passive Optical Splitter

Name: H3C Passive Optical Splitter
Brand: H3C
SKU: H3C-OSPL

Model: OSPLSeries: All-Optical Network

Passive PON splitters in 1:2 to 1:32 and dual-uplink 2:N ratios, connecting OLTs to ONUs in compact boxes or a 1U rack unit.

Price on Request

Island-wide delivery to all 25 districts

Splitter	Size(mm)(W ×D×H) / Operating bandwidth (nm) / Insertion loss (dB) / Return loss (dB) / Polarization Dependent Loss (dB) / Connector type
1:2	90×20×10 / 1260~1650nm / ≤4.1 / ≥50 / 0.2 / SC/UPC
1:4	100×80×10 / 1260~1650nm / ≤7.4 / ≥50 / 0.3 / SC/UPC
1:8	100×80×10 / 1260~1650nm / ≤10.5 / ≥50 / 0.3 / SC/UPC
1:16	120×80×18 / 1260~1650nm / ≤13.8 / ≥50 / 0.3 / SC/UPC
1:32	120×80×18 / 1260~1650nm / ≤16.9 / ≥50 / 0.3 / SC/UPC
1:32（1U box）	483×200×44.5 / 1260~1650nm / ≤16.9 / ≥50 / 0.6 / SC/UPC
2:2	90×20×10 / 1260~1650nm / ≤4.4 / ≥50 / 0.3 / SC/UPC
2:4	100×80×10 / 1260~1650nm / ≤7.7 / ≥50 / 0.3 / SC/UPC
2:8	100×80×10 / 1260~1650nm / ≤10.9 / ≥50 / 0.3 / SC/UPC
2:16	120×80×18 / 1260~1650nm / ≤14.3 / ≥50 / 0.3 / SC/UPC
2:32	120×80×18 / 1260~1650nm / ≤17.4 / ≥50 / 0.4 / SC/UPC
Fiber type	G.657.A2
Fiber diameter(mm)	2
Fiber length(m)	1
Storage Temperature	-40℃ ~ 85℃
Operating Temperature	-40℃ ~ 85℃
Operating & Storage Relative Humidity	≤95% (noncondensing)
