A disaggregated (DDC) 800G/400G fabric for AIGC clusters, scaling to 4,608 x 800G or 9,216 x 400G ports.
Island-wide delivery to all 25 districts
| Models | S12500AI-18EP20EP-NCPN, S12500AI-36DH20EP-NCPN, S12500AI-NCFN |
|---|---|
| Switching capacity | S12500AI-18EP20EP-NCPN: 14.4T; S12500AI-36DH20EP-NCPN: 14.4T; S12500AI-NCFN: 102.4T |
| Packet forwarding rate | S12500AI-18EP20EP-NCPN: 5.4B; S12500AI-36DH20EP-NCPN: 5.4B; S12500AI-NCFN: - |
| Interfaces | S12500AI-18EP20EP-NCPN: 18*OSFP 800G+20*OSFP 800G; S12500AI-36DH20EP-NCPN: 36*QSFP-DD 400G+20*OSFP 800G; S12500AI-NCFN: 128*OSFP 800G |
| Console port | RJ45 *1 |
| Out-of-band management port | RJ45 *1 |
| USB port | Type-C *1 |
| Dimensions (H× W × D, with package) (mm) | S12500AI-18EP20EP-NCPN: 255×590×1135; S12500AI-36DH20EP-NCPN: 255×590×1135; S12500AI-NCFN: 465×670×980 |
| Dimensions (H× W × D,no package) (mm) | S12500AI-18EP20EP-NCPN: 88.1×440×760; S12500AI-36DH20EP-NCPN: 88.1×440×760; S12500AI-NCFN: 308.4×442×640 |
| Weight (no package) (kg) | S12500AI-18EP20EP-NCPN: 17.2kg; S12500AI-36DH20EP-NCPN: 17.3kg; S12500AI-NCFN: 33.7kg |
| Weight (with package) (kg) | S12500AI-18EP20EP-NCPN: 21.59kg; S12500AI-36DH20EP-NCPN: 21.69kg; S12500AI-NCFN: 65.94kg |
| Height(RU) | S12500AI-18EP20EP-NCPN: 2; S12500AI-36DH20EP-NCPN: 2; S12500AI-NCFN: 7 |
| Power supply | S12500AI-18EP20EP-NCPN: 2(1+1 Redundancy), AC; S12500AI-36DH20EP-NCPN: 2(1+1 Redundancy), AC; S12500AI-NCFN: 6(3+3 Redundancy),AC |
| Fan | S12500AI-18EP20EP-NCPN: 4; S12500AI-36DH20EP-NCPN: 4; S12500AI-NCFN: 12 |
| Typical Power Consumption | S12500AI-18EP20EP-NCPN: 660W (Ports using cables) 1192W (Ports using typical optical transceiver modules); S12500AI-36DH20EP-NCPN: 694W (Ports using cables) 1233W (Ports using typical optical transceiver modules); S12500AI-NCFN: 1300W (Ports using cables) 3092W (Ports using typical optical transceiver modules) |
| Static Power Consumption | S12500AI-18EP20EP-NCPN: 322W; S12500AI-36DH20EP-NCPN: 322W; S12500AI-NCFN: 680W |
| Maximum Power Consumption | S12500AI-18EP20EP-NCPN: 2135W; S12500AI-36DH20EP-NCPN: 2120W; S12500AI-NCFN: 5640W |
| Typical Heat Dissipation | S12500AI-18EP20EP-NCPN: 2055.45 BTU/h; S12500AI-36DH20EP-NCPN: 2055.45 BTU/h; S12500AI-NCFN: 3846.12 BTU/h |
| Maximum Heat Dissipation | S12500AI-18EP20EP-NCPN: 6302.15 BTU/h; S12500AI-36DH20EP-NCPN: 6131.54 BTU/h; S12500AI-NCFN: 16296.19 BTU/h |
| MTBF(year) | S12500AI-18EP20EP-NCPN: 38.382; S12500AI-36DH20EP-NCPN: 38.209; S12500AI-NCFN: 22.038 |
| MTTR(h) | 0.5 |
| Availability | S12500AI-18EP20EP-NCPN: 0.9999985; S12500AI-36DH20EP-NCPN: 0.99999849; S12500AI-NCFN: 0.99999739 |
| DRAM Memory | 32G |
| NOR Flash | 32MB*2 |
| Nand Flash | 64GB |
| SSD | 240GB M.2 SATA (Optional) |
| Operating temperature | 0°C to 40°C |
| Storage temperature | -40ºC～70ºC |
