Smart-managed Layer 3 lite gigabit switches with IRF2 stacking and PoE options for SMB access.
Island-wide delivery to all 25 districts
| Models | S5120V3-10P-LI, S5120V3-10P-PWR-LI, S5120V3-20P-LI, S5120V3-28P-LI |
|---|---|
| Switching capacity | S5120V3-10P-LI: 20Gbps; S5120V3-10P-PWR-LI: 20Gbps; S5120V3-20P-LI: 40Gbps; S5120V3-28P-LI: 56Gbps |
| Forwarding capacity | S5120V3-10P-LI: 15Mpps; S5120V3-10P-PWR-LI: 15Mpps; S5120V3-20P-LI: 30Mpps; S5120V3-28P-LI: 41.7Mpps |
| CPU | 1 Core, 800MHz |
| Flash/SDRAM | 256MB/512MB |
| Dimensions (W × D × H) | S5120V3-10P-LI: 266×161×43.6 mm; S5120V3-10P-PWR-LI: 330×230×43.6 mm; S5120V3-20P-LI: 330×230×43.6 mm; S5120V3-28P-LI: 440×160×43.6 mm |
| Weight | S5120V3-10P-LI: ≤ 1.5 kg; S5120V3-10P-PWR-LI: ≤ 3 kg; S5120V3-20P-LI: ≤ 2 kg; S5120V3-28P-LI: ≤ 2.5 kg |
| Management port | 1 console port |
| Networking interface | S5120V3-10P-LI: 8*10/100/1000TX+ 2*SFP; S5120V3-10P-PWR-LI: 8*10/100/1000TX+ 2*SFP; S5120V3-20P-LI: 16×10/100/1000TX+4×SFP; S5120V3-28P-LI: 24×10/100/1000TX+4×SFP |
| Maximum Stacking bandwidth | 16Gbps |
| Maximum stacking num | 9 |
| Port Surge | 6KV |
| Input voltage | AC: The rated voltage range is 100V to 240V, 50/60Hz. |
| Total power consumption | S5120V3-10P-LI: MIN: AC: 8W MAX: AC: 15W; S5120V3-10P-PWR-LI: MIN: AC: 14W MAX: AC: 156W (PoE 125W); S5120V3-20P-LI: MIN: AC: 9W MAX: AC: 19W; S5120V3-28P-LI: MIN: AC: 9W MAX: AC: 23W |
| Fan number | Fan-less |
| MTBF(Year) | S5120V3-10P-LI: 140.82; S5120V3-10P-PWR-LI: 117.08; S5120V3-20P-LI: 136.24; S5120V3-28P-LI: 150.86 |
| MTTR(Hour) | 1 |
| Operating temperature | -5℃ ~ 50℃(normal operating temperature) -5℃ ~ 45℃(When using transceiver modules with maximum transmission distance < 80km) -5℃ ~ 40℃(When using transceiver modules with maximum transmission distance ≥ 80km) |
| Storage temperature | -40℃ ~ 70℃ |
| Relative humidity (non-condensing) | 5% RH to 95% RH, non-condensing |
| Models | S5120V3-52P-LI, S5120V3-28P-PWR-LI, S5120V3-28P-HPWR-LI, S5120V3-52P-PWR-LI, S5120V3-28F-LI |
| Models | S5120V3-28S-LI, S5120V3-52S-LI, S5120V3-28S-HPWR-LI, S5120V3-28S-PWR-LI, S5120V3-52S-PWR-LI |
| Port aggregation | GE/10GE port aggregation Dynamic aggregation Static aggregation Cross-device aggregation |
| Broadcast/Multicast/Unicast storm suppression | Storm suppression based on port bandwidth percentage Storm suppression based on PPS Storm suppression based on BPS Broadcast traffic/Multicast traffic/Unknown unicast traffic suppression |
| Traffic control | 802.3x traffic control and half-duplex backpressure |
| IRF2 | Distributed device management, distributed link aggregation, and distributed resilient routing Stacking through standard Ethernet interfaces Local device stacking and remote device stacking |
| MAC address table | Static MAC address Blackhole MAC address Setting the maximum number of port MAC addresses to be learned |
| VLAN | Port-based VLAN MAC-based VLAN Protocol-based VLAN QinQ and selective QinQ VLAN mapping Voice VLAN MVRP |
