H3C S6526XE-EI Series Advanced Aggregation 10GE Switches

Model: S6526XE-EISeries: S6526

10GE aggregation switches with four 100G uplinks, two expansion slots and a 32 MB buffer.

32 or 48 x 1/10G SFP+ and 4 x 40/100G QSFP28
Two expansion slots
2.56 Tbps switching, 32 MB buffer
Quad-core CPU, 4 GB RAM
Embedded AC and IRF2

Price on Request

Request Price Call 076 018 7080 Download datasheet

Island-wide delivery to all 25 districts

Models	S6526XE-32X4CC-EI, S6526XE-48X4CC-EI
Port switching capacity	S6526XE-32X4CC-EI: 2240Gbps; S6526XE-48X4CC-EI: 2560Gbps
Packet forwarding rate	1002Mpps
System switching capacity	2.56Tbps
CPU	Quad core, 2GHz
SDRAM	4GB
Flash	4GB
Packet buffer	32M
Latency	10GE:<3 (64byte/us) 100GE:<1 (64byte/us)
Dimensions (H × W × D)	44 × 440 × 400 mm (1.73 × 17.32 × 15.75 in)
Weight	S6526XE-32X4CC-EI: ≤ 8.1 kg; S6526XE-48X4CC-EI: ≤ 8.2 kg
Console ports	1 RJ45 and 1 Type-C
Management Ethernet ports	1 RJ45 port (Out of Band)
USB ports	1
SFP+	S6526XE-32X4CC-EI: 32; S6526XE-48X4CC-EI: 48
QSFP28	4
Latency (64byte LIFO)	10GE:<3μs 100GE:<1μs
Expansion slots	2
Input voltage range	AC: Rated: 100 VAC to 240 VAC @ 50 Hz/60 Hz Max: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
Power supply slots	1+1 hot swappable
Fan trays	1+1 hot swappable
Power consumption (static) Data collection standard: no load	S6526XE-32X4CC-EI: Single AC: 75W Dual AC: 83W Single DC: 74W Dual DC: 82W; S6526XE-48X4CC-EI: Single AC:72W Dual AC:82W Single DC:72W Dual DC: 81W
Power consumption (with typical configuration) Data collection standard: fully c	S6526XE-32X4CC-EI: Single AC: 91W Dual AC: 98W Single DC: 94W Dual DC: 101W; S6526XE-48X4CC-EI: Single AC:100W Dual AC:108W Single DC:103W Dual DC: 112W
Power consumption (fully configured) Data collection standard: fully configured	S6526XE-32X4CC-EI: Single AC: 239W Dual AC: 243W Single DC: 249W Dual DC: 250W; S6526XE-48X4CC-EI: Single AC: 275W Dual AC: 277W Single DC: 279W Dual DC: 283W
MTBF(Year)	S6526XE-32X4CC-EI: 41.02; S6526XE-48X4CC-EI: 39.98
MTTR(Hour)	1
Operating temperature	-5ºC to 45ºC (23ºF to 113ºF) From -60m to 5000m altitude: From 0m, the maximum operating temperature reduce by 0.33ºC for every time 100 the altitude increases by 100m.
Storage temperature	-40ºC to 70ºC (-40ºF to 158ºF)
