H3C S9855-G Data Center Switches

Name: H3C S9855-G Data Center Switches
Brand: H3C
SKU: H3C-S9855-G

Model: S9855-GSeries: S9855

Compact 1U 400G/200G switches for next-generation data-centre leaf and spine layers.

Price on Request

Island-wide delivery to all 25 districts

Models	S9855-24B16DH-G, S9855-32DH-G
Dimensions (H × W × D) /mm	44 × 442 × 550
Weight	≤12.3kg
Console port	1
Out-of-band management port	10M/100M/1000M Base-T port：1
USB port	1
SFP28 port	S9855-24B16DH-G: -; S9855-32DH-G: 2
200G QSFP56 port	S9855-24B16DH-G: 24; S9855-32DH-G: -
400G Q112 port	S9855-24B16DH-G: 16; S9855-32DH-G: 32
CPU	2.2GHz
Flash/SDRAM	NAND FLASH:SSD 128G RAM: 16G
Latency	1μs
Buffer	64MB
Switching capacity	S9855-24B16DH-G: 22.4T（bidirection）; S9855-32DH-G: 25.6T（bidirection）
Forwarding capacity	5.6Bpps
AC-input voltage	100V-240V AC；50/60Hz
DC-input voltage	240V DC
Power module slot	2
Fan tray slot	6
Air flow direction	Port Panel and Fan Panel Side Exhaust Airflow
Static power consumption	S9855-24B16DH-G: Single power:232W/ Dual power:247W; S9855-32DH-G: Single power:258W/ Dual power:272W
Typical power consumption(full cables, 50% load)	S9855-24B16DH-G: Single power:320W/ Dual power:331W; S9855-32DH-G: Single power:344W/ Dual power:350W
Typical power consumption(full transceivers, 100% load)	S9855-24B16DH-G: Single power:907W/ Dual power:909W; S9855-32DH-G: Single power:980W/ Dual power:939W
MTBF(years)	S9855-24B16DH-G: 67.7; S9855-32DH-G: 45.07
MTTR(hour)	0.5
Operating temperature	0ºC～40ºC
Storage temperature	-40ºC～70ºC
Operating humidity	5%～95%
