A next-generation aggregation router on Comware 9 with up to 600 Gbps forwarding and 40 Gbps SD-WAN encryption.
Island-wide delivery to all 25 districts
| Models | SR6608-M, SR6616-M |
|---|---|
| IP forwarding performance (IMIX) | SR6608-M: RFU-860-G: 600Gbps RFU-560-G: 320Gbps RFU-360-G: 320Gbps; SR6616-M: RFU-860-G: 600Gbps |
| Forwarding performance withACL+NAT+QoS (IMIX) | SR6608-M: RFU-860-G: 70Gbps RFU-560-G: 50Gbps RFU-360-G: 15Gbps; SR6616-M: RFU-860-G: 95Gbps |
| IPsec forwarding performance (1400byte) | SR6608-M: RFU-860-G: 32Gbps RFU-560-G: 15.5Gbps RFU-360-G: 6.5Gbps; SR6616-M: RFU-860-G:36.5Gbps |
| IPsec tunnel | SR6608-M: RFU-860-G: 60,000 RFU-560-G: 20,000 RFU-360-G: 10,000; SR6616-M: RFU-860-G: 60,000 |
| AD-WAN typical encryption performance (IMIX) | SR6608-M: RFU-860-G with ESPA: 40Gbps RFU-560-G with ESPA: 18Gbps; SR6616-M: RFU-860-G with ESPA: 40Gbps |
| RFU | 2 (1:1 redundancy) |
| HMIC | SR6608-M: 8; SR6616-M: 16 |
| Heat dissipation | Front-rear, cut-through air aisles |
| Fan tray | 2, operating in redundancy |
| Power system | SR6608-M: 4 power supplies, N+M redundancy Rated AC input range: 100 to 240 VAC @ 50/60 Hz Rated DC input range: –48 to –60 VDC; SR6616-M: 6 power supplies, N+M redundancy Rated AC input range: 100 to 240 VAC @ 50/60 Hz Rated DC input range: –48 to –60 VDC |
| Dimensions (H × W × D) | SR6608-M: 175 × 440 × 330 mm (6.89 × 17.32 × 12.99 in), 4 U; SR6616-M: 442 × 350 × 263.9 mm (17.40 × 13.78 × 10.39 in)，6 U |
| Operating temperature | 0°C to 45°C |
| Operating altitude | < 5000m |
| Operating humidity | 5 to 95%, non-condensing |
| System power consumption | SR6608-M: 610W; SR6616-M: 1294W |
| Weight (fully configured) | SR6608-M: 22.7Kg; SR6616-M: 37.8Kg |
| Interface type | FE, GE, 10GE, 40GE, 50GE, 100GE interfaces 155M POS, 622M POS interfaces E1-F/E1 interface |
| EMC standards compliance | FCC Part 15 Subpart B CLASS A ICES-003 CLASS A VCCI-CLASS A CISPR 32 CLASS A EN 55032 CLASS A AS/NZS CISPR32 CLASS A CISPR 35 EN 55035 EN 61000-3-2 EN 61000-3-3 ETSI EN 300 386 GB/T 9254.1 |
| Safety standards compliance | FDA 21 CFR Subchapter J UL 62368-1 CAN/CSA C22.2 No 62368-1 IEC 62368-1 EN 62368-1 |
| Environment standards compliance | IEC 60068-2-1 IEC 60068-2-2 IEC 60068-2-78 IEC 60068-2-30 IEC 60068-2-14 |
| Shock and vibration standards compliance | IEC 60068-2-64 IEC 60068-2-31 |
| Ethernet | ARP QinQ Termination Link aggregation, including dynamic aggregation and static aggregation Aggregation of interface with different rates Port mirroring, flow mirroring FlexE Interface channelization |
| IP service | NAT, NAT444, NAT multi-instance, VPN NAT, NAT logging NetStream v5/v8/v9 packet format, IPv4/IPv6/MPLS packet statistics Network Quality Analyzer (NQA) DNS, DNS proxy DHCP server, DHCP relay, DHCP client UDP helper |
| IPv6 | IPv6 ND, IPv6 PMTU, dual-stack forwarding IPv6 ACL DHCPv6 server/client DNS AAA request, proxy IPv6 tunneling: Manual IPv6 tunneling, IPv6-over-IPv4 tunneling, GRE tunneling, automatic IPv4-compatible IPv6 tunneling, 6to4 tunneling, ISATAP tunneling 6PE, 6VPE (IPv6 MPLS L3VPN) NAT64, NAT46 NATPT, NPTv6 |
| Unicast routing | IPv4 and IPv6 dual-stack Static routing, RIP, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+ VRRP, VRRPv3 IPv4 to IPv6 transition ECMP, UCMP Policy-based routing Routing policy Static routing, FRR, OSPF FRR, ISIS FRR, BGP FRR |
| Mulitcast | PIM-DM, PIM-SM, PIM-SSM, MSDP, MBGP, anycast-RP IGMPv1/v2/v3 PIM6-DM, PIM6-SM, PIM6-SSM Multicast Listener Discovery (MLDv1/v2) Multicast policy and multicast QoS |
| MPLS VPN | MPLS label distribution protocol including LDP and RSVP-TE P/PE, compliant with RFC2547bis Inter-AS MPLS VPN options (Option A/Option B/Option C) HoPE Multi-role host Layer 2 VPN, Layer 3 VPN, inter-AS Layer 2 VPN, inter-AS Layer 3 VPN MPLS TE FRR, LDP FRR 6PE, 6vPE Multicast VPN MPLS VPN failure location, MPLS ping/traceroute L2VPN access to L3VPN |
